Fluoroscopy and Special Radiographic Techniques
Page Navigation
53

SUGGESTED STARTING TECHNIQUE

HOLDER

*CM

KVP

MAS

SID

GRID

CONE

Cassette

18-22

90

20

40"

8:1

Film coverage

HIGH KILOVOLTAGE TECHNIQUE

HOLDER

CM

KVP

MAS

SID

GRID

CONE

Cassette

18-22

125

10

40"

8:1

Film coverage

Figure 2-14. Radiograph of the large bowel, PA or AP with double contrast.

MD0959

2-19
